4/4 Black Flat Festoon Cable (Neoprene)

Cut to length - sold by the foot. Enter the desired footage in the QTY box.
Minimum 25 ft. to maximum 1000 ft. Please call for longer put ups.

Color:
Black

Applications:
Flexible power and control cable, for use on festoon systems and for connecting moveable parts of machine tools, material handling equipment, etc., associated with high mechanical stresses and frequent bending during operation and for bending in one plane only.

Features:
Neoprene Flat Festoon cable has extra flexible bare stranded copper conductors, Ethylene Propylene Rubber (EPR) insulation, Neoprene jacket overall, flat construction, VDE and UL approved, 90°C, 600V.  Weather resistance: unrestricted use outdoors and indoors, resistant to ozone, UV and moisture

Standards:
DIN VDE 0250, Part 809
UL File E 113313
GOST R

Jacket Material:
Neoprene - Polychloroprene

Conductor Material:
Bare Copper

Specifications*:

Size: 4 AWG
Number of Conductors: 4
Conductor Strand: 750
Outside Diameter: 0.550 x 1.810 inches
Weight: 1.061 lbs per ft
Voltage: 600V
